Brush type self-cleaning filter
Service pressure: 0.2 ~ 2.5MPa
Filter element material: 304, 316L, 2205
Service temperature: W80 ° C
Cleaning brush material: 304, 316L
Service voltage: 380V 50Hz
Cleaning method: brush type
Backwashing water consumption: W 2%
Cleaning time: 60s adjustable
Filtration accuracy: 50 ~ 5000 microns
Control mode: manual, automatic (differential pressure, time)
Tank material: Q235B, 304, 316L, carbon steel rubber lining
Ask For Quote
Brush type self-cleaning filter
The optional range of filtering accuracy is 50 to 5000 microns. The filter has large filtration area and high pollution absorption ability. Users can customize the filter according to the actual working conditions. The cleaning method is simple, and the cleaning cycle monitoring can realize automatic cleaning and sewage. All parameters of the automatic filter control system can be adjusted. The filter is equipped with motor overload protection function, which can effectively protect the motor.
Application
Agricultural irrigation, raw water treatment, industrial circulating water filtering, cooling water treatment, paper industry, plastic industry, power industry and other industries.
Filter medium
Suspended solids, particulate matter, water quality dirt, bacteria and algae, corrosion, etc
| Model | Tank specification | Inlet & outlet specification | Maximum flow t/h | Accuracy class | Motor power / reducer Model |
|---|---|---|---|---|---|
| LFZ-250-50 | Φ273*1000 | DN25-DN50 | 50 | ≥50μm | 0.18KW/RV040 |
| LFZ-300-100 | Φ325*1200 | DN80-DN125 | 100 | ≥100μm | 0.37KW/RV063 |
| LFZ-400-150 | Φ426*1300 | DN150 | 200 | ≥200μm | |
| LFZ-480-200 | Φ480*1550 | DN200 | 300 | >≥300μm | |
| LFZ-530-250 | Φ530*1650 | DN250 | 450 | ≥300μm | 0.75kw/RV075 |
| LFZ-600-300 | Φ600*1750 | DN300 | 550 | ≥300μm | |
| LFZ-700-350 | Φ700*2000 | DN350 | 700 | ≥500μm | |
| LFZ-800-400 | Φ800*2150 | DN400 | 1000 | ≥800μm | |
| LFZ-900-450 | Φ900*2300 | DN450 | 1200 | ≥1000μm | |
| LFZ-1000-500 | Φ1000*2500 | DN500 | 1500 | ≥1500μm | |
| LFZ-1100-600 | Φ1100*2600 | DN600 | 1800 | ≥3000μm | 1.5kw/RV090 |
| LFZ-1200-700 | Φ1200*2800 | DN700 | 2300 |
PLC control system:
Automatic identification of internal impurities deposition degree;
Multiple control modes: differential pressure control, time setting control, manual control;
One key switch, automatic operation;
Can be customized according to the actual working conditio
High-performance precision filter:
Adopt 304/316L stainless steel wedge metal mesh filter element;
Support 20-500um customization;
Not easy to plug, easy to clean, low pressure loss, low maintenance cost;
Be used for liquid viscosity up to 8000 cp.
Key components:
Imported bipolar reducer and electrical components;
PLC Siemens control system;
Optional electric ball valve;
The whole equipment system can run efficiently and stably.
Features
Automatic self-cleaning filter has the function of filtering the raw water and cleaning the filter element automatically, and the system will provide uninterrupted water supply during self-cleaning and sewage draining process.
There are two kinds of control mode: automatic control and manual control.
Automatic control: Automatic control has two ways of timing and differential pressure.
Timing control: Set the filtration time on the filtration timer. When the filtration time is up, the sewage discharge is started, and the sewage discharge time is set by the sewage discharge timer.
Differential pressure control: At the same time, the control system will compare the pressure difference of the system with the pressure difference set by the user in real time. When the pressure difference of the system reaches the setting value, the filter will also clean the the filter element and discharge sewage automatically, and the sewage discharge time is set by the sewage discharge timer. When the sewage discharge time is up, the filter will stop self-cleaning process and restore the system to its initial state to prepare for the next filtration process.
Manual control: Turn the manual/automatic selector switch on the operation panel to the manual position to discharge sewage.Brush type self-cleaning filter working principle
