PLF series pressure pipeline filter

This series of filters can be installed on pressure pipelines with different pressure levels to filter out mechanical impurities mixed in hydraulic oil and impurities caused by chemical changes of hydraulic oil itself.It is especially suitable for automatic control system and servo system.It can prevent high-precision control elements and executive elements from being prematurely worn or stuck due to pollution,so as to reduce faults and prolong the service life of elements.

The filter element is made of chemical fiber,which has the advantages of high filtration accuracy,large oil passing capacity,small original pressure loss,high pollutant carrying capacity and so on.The filtration accuracy is calibrated by absolute filtration accuracy,the filtration ratioβ3,5,10,20≥200, filtration efficiency N≥99.5%,in line with ISO standards.

Application

widely used in hydraulic systems such as heavy machinery,mining machinery and metallurgical machinery.

Filter medium

water and ethylene glycol in hydraulic oil

Note:*refers to filtration accuracy.If the medium is water-glycol,service pressure is 32MPa,nominal flow rate is 60L/min,filtration accuracy is 10μm,with transmitter,the filter model is PLFOBH-H60x10P,and the filter element model is LH0060D010BN3HC.

Connection Size

I、tubular

1、32MPa pressure pipeline filter

Model	Size (mm)
	~H	~H1	H2	H3	H4	h	L	L1	L2	D	M	d2
PLF-H30 x *P	239	146	58	45		35	118	114	69	73	2 - M33 x 2	2-M10
PLF-H60 X *P	255	162	58	45		35	118	114	69	73	2 - M33 x 2	2-M10
PLF-H110x*P	329	236	58	45		35	118	114	69	73	2-M42x2	2-M10
PLF-H160x*P	319	215	69	49	45	50	150	140	82	102	2-M48X2	4-M10

2、16MPa pressure pipeline filter

Model	Size (mm)
	~H	~H1	H2	H3	H4	h	L	L1	L2	D	M	d2
PLF-E30 x *P	223	136	52	39		35	110	100	62	73	2 - M33 x 2	2-M10
PLF-E60 X *P	239	152	52	39		35	110	100	62	73	2 - M33 x 2	2-M10
PLF-E110x*P	308	221	52	39		35	110	100	62	73	2-M42x2	2-M10
PLF-E160x*P	294	196	63	43	45	45	140	130	77	95	2-M48x2	4-M10

3、6.3MPa pressure pipeline filter

Model	Size (mm)
	~H	~H1	H2	H3	H4	h	L	L1	L2	D	M	d2
PLF - C30 X *P	223	136	52	39		35	110	88	56	73	2 - M33 x 2	2-M10
PLF - C60 x *P	239	152	52	39		35	110	88	56	73	2 - M33 x 2	2-M10
PLF - C110 x *P	308	221	52	39		35	110	88	56	73	2-M42x2	2-M10
PLF - C160 X *P	290	196	59	39	45	45	140	114	69	95	2-M48x2	2-M10

II、flange type

1、32MPa pressure pipeline filter

Model	Size (mm)
	~H	~H1	H2	H4	H5	h	h1	h2	h3	h4	L	L1	L2	D	d	d1	d2
PLF-H242 x *FP	377	273	69	45	49	50	79.4 ±0.25	110	36.5 ±0.25	90	150	140	82	102	2-Φ38	4-M16	4-M10
PLF-H333 x *FP	400	277	88	60	63	80	96.8 ±0.25	130	44.5 土 0.25	110	190	180	108	146	2-Φ51	4-M20	4-M12
PLF-H500 x *FP	493	370	88	60	63	80	96.8 ±0.25	130	44.5 土 0.25	110	190	180	108	146	2-Φ51	4-M20	4-M12
PLF-H666 x *FP	567	444	88	60	63	80	96.8 ±0.25	130	44.5 土 0.25	110	190	180	108	146	2-Φ51	4-M20	4-M12

2、16MPa pressure pipeline filter

Model	Size (mm)
	~H	~H1	H2	H4	H5	h	h1	h2	h3	h4	L	L1	L2	D	d	d1	d2
PLF-E240 x *FP	352	254	63	45	43	45	69.9 ±0.25	94	35.7 ±0.25	82	140	130	77	95	2-Φ38	4-M12	4-M10
PLF-E330 x *FP	368	257	76	55	56	75	77.8 ±0.25	102	42.9 土 0.25	96	180	164	100	140	2-Φ51	4-M12	4-M12
PLF-E500 x *FP	461	350	76	55	56	75	77.8 ±0.25	102	42.9 土 0.25	96	180	164	100	140	2-Φ51	4-M12	4-M12
PLF-E660 x *FP	535	424	76	55	56	75	77.8 ±0.25	102	42.9 土 0.25	96	180	164	100	140	2-Φ51	4-M12	4-M12

3、6.3MPa pressure pipeline filter

Model	Size (mm)
	~H	~H1	H2	H4	H5	h	h1	h2	h3	h4	L	L1	L2	D	d	d1	d2
PLF-C240x*FP	348	254	59	45	39	45	69.9 ±0.25	94	35.7 ±0.25	82	140	114	69	95	2-Φ38	4-M12	4-M12
PLF-C330x*FP	350	249	66	55	46	65	77.8 ±0.25	102	42.9 ±0.25	96	180	144	90	133	2-Φ51	4-M12	4-M12
PLF-C500x*FP	443	342	66	55	46	65	77.8 ±0.25	102	42.9 ±0.25	96	180	144	90	133	2-Φ51	4-M12	4-M12
PLF-C660x*FP	517	416	66	55	46	65	77.8 ±0.25	102	42.9 ±0.25	96	180	144	90	133	2-Φ51	4-M12	4-M12

1、Compared with the same flow filter,it has compact structure and small volume.

2、Wide pressure range.

3、It is convenient to change the filter element.Users can open the upper cover and replace the filter element according to the installation space,or unscrew the shell (drain the oil first) and remove the filter element from below.

4、Convenient installation and fixation:if the user has difficulty in installing according to the standard flow direction,remove the four screws on the cover and turn the cover 180 degrees.This changes the flow direction of the medium.

5、The filter is equipped with by-pass valve and differential pressure signal device,with dual protection function.When the filter element is polluted and blocked until the inlet and outlet pressure difference is the set value of the transmitter,the transmitter sends a message,and the filter element must be replaced at this time.
